ERNiCrMO-10 Nickel Based Welding Wire Nickel Chromium Molybdenum Alloy

Name: ERNiCrMO10 Nickel Based Welding Wire Nickel Chromium Molybdenum Alloy
Brand: KAIXIN
Price: 1 USD

ERNiCrMO-10 Nickel Based Welding Wire Nickel Chromium Molybdenum Alloy Manufactures

Brand Name : KAIXIN

Model Number : KX-Alloy Mo-10

Certification : ISO9001:2015

Place of Origin : China

MOQ : 200KG

Price : To negotiate

Payment Terms : T/T, L/C

Supply Ability : 50~80TONS PER MONTH

Delivery Time : 45~60days

Packaging Details : Wooden Box, size as per guests request

Alloy Type : Nickel chromium molybdenum Alloy

Delivery State : Sosoloid

Size : Negotiable

Shape : Parcel Wire, Barrel Wire, Vertical Strip

Raw Materials : NI Rem,MO12.5-14.5%, CR20.0-22.5%

Executive Standard : GB/T15620-2008，AWS A5.14 :2005

Application : Petrochemical pipeline and valve surfacing welding

Features : Used for welding of low carbon nickel chromium molybdenum, especially for UNS No6002 welding, but also for the welding of chromium-nickel-molybdenum austenitic stainless steel, low carbon Nichromo double core surface and other nickel-based alloys.

Contact Now

KX ERNiCrMO-10 Welding Wire Light Rod on Nickel Based Welding Wire Alloy

Product Description and Application

ERNiCrMo - 4 is also known as N10276 SNi6276, NiCr15Mo16Fe6W4

Ernicrmio-4 is 57Ni16Cr15.5Mo nickel-base welding wire for nickel-chromium-molybdenum series. The fused metal has good mechanical properties, good resistance to pitting corrosion and crevice corrosion in various corrosive medium. It includes stable arc, beautiful forming, good flow of molten iron with excellent welding process performance.

Process Performance and Requirements

Product Fusion Process

Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)

Product Chemical Composition

Wire Type

Composition

Code

AWS

A5.14:2005

Ni^a

Co^a

SN16022

NiCr21Mo13Fe4W3

ERNiCrMO-10

≤

0.01

≤

0.5

2.0

6.0

≤

0.1

≤

0.5

≧

49.0

≤

2.5

20.0

22.5

12.5

14.5

2.5

3.5

Other Technical Requirements

Welding Wire Diameter and Allowable Deviation

Package	Welding Wire Diameter	Allowable Deviation
Vertical Bar	1.6,1..8,2.0,2.4,2.5,2.8,3.0,3.2, 4.0,4.8,5.0,6.0,6.4	±0.1
Welding Wire Coil	1.6,1..8,2.0,2.4,2.5,2.8,3.0,3.2, 4.0,4.8,5.0,6.0,6.4	+0.01 -0.04
Wire Reel Diameter 100mm and 200mm	0.8,0.9,1.0,1.2,1.4,1.6
Wire Reel Diameter 270mm and 300mm	0.5,0.8,0.9,1.0,1.2,1.4,1.6,2.0, 2.4,2.5,2.8,3.0,3.2
Welding wire can be produced in other sizes, deviations and package as agreed by both parties
Allowable deviation of ±0.1 diameter when used for hand-filled wire

Welding Wire Loose Diameter and Warp Pitch

Diameter of Wire Reel	100	200	270,300
Loose Diameter	60~380	250~890	380~1300
Warp Pitch	≤13	≤19	≤25

Productive Process

ERNiCrMO-10 Nickel Based Welding Wire Nickel Chromium Molybdenum Alloy

Professional Customization

Cold-drawn Wire	¢0.3~¢18mm(Delivery in rolls or trays)
Hot-Rolling Wire	¢5.5~¢20mm(Delivery in rolls)
Strip	thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips)
Smooth Forged Rod on a Lathe	¢60~350mm,L800-2500mm
Hot-rolled Burnishing	¢20~80mm,L1000-5000mm
Cold Drawn and Burnishing	¢2.5~18mm,L1000-8000mm
Seamless Tube	¢1~275mm,wall thickness 0.2~30,L1000-8000mm

ERNiCrMO-10 Nickel Based Welding Wire Nickel Chromium Molybdenum Alloy
